WinGD X72 - Page 263

Operation
4002−1/A1
Winterthur Gas & Diesel Ltd.
19/ 22
Fuel Rail
Fuel
Injection
Valve
All components are shown in
the NO INJECTION position
Solenoid Valve
Outlet Throttle
Control
Fuel out
Control
Space
Needle
Injection
Valve
Outlet Throttle
Fig. 9: Fuel Injection Control
Engine Control System
2015-12
