Operation4002−2/A1
Winterthur Gas & Diesel Ltd.
22/ 37
Item Function Effect / Procedure
16 Angle detection / Angle
determination failure indication
Shows the angle determination status. When the
crank angle determination algorithm (ADA) mode is
active, the related indicator is on. When there is a
crank angle determination failure, the related
indicator is on.
17 Slow turning / Slow turning failure
indications
Shows the slow turning status. When the slow
turning mode is active, the related indicator is on.
When there is a slow turning failure, the related
indicator is on.
To reset a slow turning failure indication, move the
cursor to the reset button. Then push the rotary
button to reset the failure indication.
Local Control Panel / Local Display Unit (LDU−20)
2015-12
