Operation4002−2/A1
Winterthur Gas & Diesel Ltd.
24/ 37
Item Function Effect / Procedure
13 Fuel rail pressure Shows the fuel rail pressure in bar
14 Scavenge air pressure at
CMCR
Shows the scavenge air pressure at CMCR in bar
15 Scavenge air pressure Shows the scavenge air pressure in bar
16 Active nozzles Shows the number of active injection nozzles
17 Engine speed Shows the engine speed in revolutions per minute (rpm)
18 Engine speed Shows the engine speed in percent (%) of CMCR
19 Fuel command Shows the used fuel command in percent (%)
20 Engine load Shows the engine load or estimated engine power in
percent (%)
21 Variable injection
timing (VIT)
Shows the variable injection timing (VIT) in degree (deg),
specified for different performance definitions (VIT A,
VIT B, VIT C or VIT D)
22 Servo oil pressure Shows the servo oil pressure in bar
23 Servo oil pressure setpoint Shows the servo oil pressure setpoint in bar
Local Control Panel / Local Display Unit (LDU−20)
2015-12
