Process Code Description
35−36HA 3/2-way valve
35−36HB 3/2-way valve
35−36HC 3/2-way valve
35−4325_E0_2 3/2-way valve
35−4325_E0_3 3/2-way valve
35−4325_E0_5 2/2-way valve
35−4605_E0_6 2-way shut-off valve
35−4605_E0_8 2-way shut-off valve
35−4605_E0_9 Restrictor
35−4606_E0_2 2-way shut-off valve
35−4606_E0_4 Needle valve
35−8353_E0_2 Ball valve
35−8606_E0_4 Ball valve
50−2751_CX_1 Exhaust valve
50−8135_E0_1 2/2-way valve
50−8135_E0_2 3/2-way valve
910−D015 Fuel booster pump
910−V113 2-way shut-off valve
910−V121 2-way shut-off valve
925− B001 Cylinder lube oil tank
990 07 SAC-LT-cooling water inlet
990 08 SAC-LT-cooling water outlet
990 25 Main lubricating oil inlet
990 33 Cylinder lub oil inlet
990 34 Leakage oil driving end outlet
990 35 Leakage oil free end outlet
990 45 Control air supply inlet
990 49 Fuel inlet
990 50 Fuel return outlet
990 51 Fuel leakage rail unit outlet
990 52 Fuel leakage outlet
990 57 Various leakage outlet
