WinGD X72 - Page 455

Operation
8019−1/A1
Winterthur Gas & Diesel Ltd.
7/ 9
1
2
2
1
I
3
4
2
1
7
WCH02552
WCH02552
WCH02552
I
6
5
Fig. 3: Leakage Inspection Point − HP Fuel Pipes to Injection Valves
1 HP fuel pipe to injection valve 5 Screw-in union
2 Flow limiter valve 6 Fuel leakage pipe
3 Fuel rail 7 Sealing face
4 Screw
2014
Fuel System
