Operation
8135−1/A1
Winterthur Gas & Diesel Ltd.
3/ 4
WCH02239
3
6
4
7
5
8
2
1
FREE END
I
See Fig 3
Fig. 2: Exhaust Waste Gate
1 Exhaust gas manifold 5 Cardan rod
2 Exhaust bypass line 6 Actuator (ZS5372C)
3 Butterfly valve 7 3/2-way solenoid valve (CV7076C)
4 Orifice 8 Air spring air pipe
Exhaust Waste Gate (Low-load Tuning)
