Operation9270−1/A1
Winterthur Gas & Diesel Ltd.
18/ 28
1
POWER
STATUS
PUSH SELECT
2
8
3
7
6
5
4
Fig. 13: Local Display Unit (LDU)
1 Color display 5 CHECK button (used to accept
2 Rotary button (16 steps in the action or enter data)
one turn. Push to select) 6 BACK button (used to cancel
3 Multi-function buttons (function the action or delete data)
is shown on the display) 7 ALARM LIST button (no function)
4 HOME button (shows the main page) 8 Power/Status LED
2016−11
Selective Catalytic Reduction System
