Maintenance5551−1/A1
Winterthur Gas & Diesel Ltd.
2/ 11
3. Removal
3.1 Preparation
1) Read the data in 0012−1 General Guidelines for Lifting Tools.
2) Stop the engine (see the Operation Manual 4002-2).
3) Set to off the main bearing oil pump.
4) Remove the applicable HP servo oil pipes (1, Fig. 2), refer to 8447−1.
5) Disconnect the applicable electrical connection (3, 4 or 5).
6) Remove the applicable oil inlet pipes (2).
Fig. 2
1
2
4
WCH03058
5
3
2015
Servo Oil Pump − Removal and Installation
