Using the Postcard Bracket
Use the following procedure for installing and using the Postcard bracket when printing
on smaller media (4 x 6 in./101.6 x 152.4 mm).
With the Postcard Bracket installed, you could print envelopes from Trays 6 and 7. The
stack height is up to 200 envelopes.
1. Slowly open one of the paper trays until it stops and remove the paper.
2. Move the paper guides out to their largest position.
3. Open the front cover of the OHCF.
4. Remove the Postcard bracket from inside the OHCF front cover.
5. Install the Postcard bracket so that it sits on the locating pins on the upper frame
and in the grooves on the bottom of the tray.
6. Tighten the thumb screw so it locks the Postcard bracket in place.
