Xerox WorkCentre 5024 Service Manual

06/2014
5-69
WC 5022/5024
Part Number Index
Parts List
Version 1.0
130K64121 PL 10.5
130K64471 PL 11.5
130K78820 PL 18.5
130K79500 PL 1.9
252W29450 PL 10.6
413W11460 PL 14.4
413W11460 PL 56.13
413W11660 PL 13.3
413W11660 PL 10.3
413W11660 PL 56.10
413W11660 PL 11.3
413W11660 PL 17.1
413W11860 PL 11.6
413W11860 PL 10.6
413W11860 PL 10.5
413W14460 PL 17.1
413W77359 PL 10.6
413W77359 PL 11.6
413W85459 PL 56.4
413W85459 PL 56.5
413W85459 PL 56.7
423W05354 PL 56.5
423W32055 PL 56.7
604K20541 PL 11.2
604K20541 PL 10.2
604K75331 PL 11.3
604K75331 PL 10.3
604K80730 PL 13.1
604K80750 PL 56.5
604K87280 PL 1.6
604K90800 PL 9.1
604K90810 PL 11.1
604K90810 PL 10.1
604K90820 PL 19.1
801E28470 PL 13.2
802E54672 PL 11.1
802E54672 PL 11.5
802E54672 PL 10.5
802E54721 PL 11.2
802E54731 PL 10.7
802E54731 PL 11.7
Table 1 Part Number Index
Part Number Part List
802E54750 PL 11.7
802E54762 PL 11.7
802E54771 PL 11.7
802E56601 PL 10.7
802K57026 PL 10.4
802E62310 PL 9.3
802K70856 PL 11.4
802E85381 PL 10.2
802E86971 PL 10.7
803E13310 PL 56.2
803E13330 PL 56.8
803E13340 PL 56.3
803E15701 PL 9.3
803E16660 PL 1.6
803E17021 PL 13.2
803E17031 PL 13.2
803E17031 PL 13.3
803E17620 PL 1.6
806E37111 PL 14.4
806E37300 PL 13.3
807E00070 PL 10.3
807E00070 PL 11.3
807E00390 PL 10.3
807E00390 PL 11.3
807E00410 PL 11.3
807E00410 PL 10.3
807E00800 PL 10.3
807E00800 PL 11.3
807E13521 PL 10.2
807E13521 PL 11.2
807E30471 PL 56.11
807E31531 PL 8.3
807E37830 PL 56.11
807E39150 PL 17.1
807E39180 PL 3.2
807E39200 PL 3.2
807E39210 PL 3.2
807E39220 PL 3.2
807E39230 PL 3.2
807E39240 PL 3.2
807E39250 PL 3.2
Table 1 Part Number Index
Part Number Part List

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
