06/2014
6-23
WC 5022/5024
6.2.1 Tools and Service Consumables
General
Version 1.0
6.2.1 Tools and Service Consumables
6.2.1.1 Tools
The following tools can be stored in the CE Basic Tool Set as standard.
6.2.1.2 Service Consumables
There are no Service Consumables unique to this model.
Whenever special consumables for the machine are required, it will be notified in a separate
technical information.
6.2.2 Consumables
*1 As the PV may differ greatly from the target value depending on the usage conditions, it
should only be regarded as a reference value.
Table 1
No. TOOL No. TOOL NAME
1 499T 00247 Test Pattern (Mono A3X1)
2 499T 00283 Test Pattern (A3) for DADF Adjustment
3 499T 00301 Screw Driver (-) 3x50
4 499T 00353 Stubby Driver
5 499T 00355 Screw Driver (+) 100 mm
6 499T 01423 Box Driver with Magnet (5.5 mm)
7 499T 01901 Side Cutting Nipper
8 499T 02005 Round Nose Plier-Safety
9 499T 02327 Digital Multi-Meter Set
10 499T 02601 Silver Scale 150 mm
11 499T 08104 Flash Light (U-3)
12 499T 08902 Brush
13 499T 09588 Needle Adapter
14 499T 07776 USB Cable For PSW
15 499T 00276 Color Test Pattern
Table 1
Consumables Product Code CRU/ERU Life End *1
Standard Capacity Toner
Cartridge
006R01573 CRU 9,000 PV
Drum Cartridge 013R00670 CRU 66,000 PV (22 PPM)
78,000 PV (24 PPM)
(343 kCycle)
To Next Page
