06/2014
6-25
WC 5022/5024
6.3.1.1 DADF Input Component Check List
General
Version 1.0
6.3.1.1 DADF Input Component Check List
6.3.1.2 IIT Input Component Check List
6.3.1.4 IOT Input Component Check List
Table 1 DADF Input Component Check List
Chain-Link Component Name UI Display Description
005-102 DADF DOCUMENT SET SENSOR H H: Document detected at DADF DOCUMENT SET SENSOR
005-110 DADF REGI. SENSOR H H: Document detected at DADF REGI SENSOR
005-206 DADF PRE REGI. SENSOR L L: Document detected at DADF PRE REGI SENSOR
005-211 DADF INVERT SENSOR L L: Document detected at DADF INVERT SENSOR
005-212 DADF INTERLOCK SWITCH H H: FEEDER OPEN SENSOR
005-213 DADF OPEN SENSOR H H: DADF PLATEN INTERLOCK OPEN
005-215 DADF TRAY SET GUIDE SENSOR 1 H H: The Actuator is not blocked.
005-216 DADF TRAY SET GUIDE SENSOR 2 H H: The Actuator is not blocked.
005-217 DADF TRAY SET GUIDE SENSOR 3 H H: The Actuator is not blocked.
005-221 DOCUMENT TRAY SIZE SENSOR 1 L L: Document detected at DOCUMENT TRAY SIZE SENSOR 1
005-222 DOCUMENT TRAY SIZE SENSOR 2 L L: Document detected at DOCUMENT TRAY SIZE SENSOR 2
005-224 SACN START H H: SCAN START signal ON detected
005-228 APS EXIST L L: APS SENSOR detected
Table 1 IIT Input Component Check List
Chain-Link Component Name UI Display Description
062-201 SHEET ABORT L L: Registers a document
062-212 IIT REGI. SENSOR L L: IIT REGI SENSOR deactuated
062-240 DADF EXIST H H: DADF not installed
062-251 APS Sensor 1 L L: Document detected
062-272 SCAN START L L: Scanning possible
062-300 Platen I/L Switch L -> H -> L L: -> H -> L: Platen closed -> Platen open
062-301 Angle Sensor H H: Platen closed
Table 1 IOT Input Component Check List
Chain-Link Component Name UI Display Description
071-105 REGI SENSOR H H: Paper detected at REGI SENSOR
071-106 FUSING UNIT EXIT SENSOR H H: Paper detected at FUSING UNIT EXIT SENSOR
071-300 L/H COVER INTERLOCK SWITCH L L: L/H COVER INTERLOCK SWITCH is closed
071-301 FRONT COVER INTERLOCK SWITCH L L: FRONT COVER INTERLOCK SWITCH is closed
072-300 STM LEFT COVER SWITCH L L: STM LEFT COVER SWITCH is closed
072-301 2TM LEFT COVER SWITCH L L: 2TM LEFT COVER SWITCH is closed
072-100 TRAY 1 NO PAPER SENSOR H H: Paper detected at TRAY 1 NO PAPER SENSOR
072-101 TRAY 2 NO PAPER SENSOR L L: Paper detected at TRAY 2 NO PAPER SENSOR
