Xerox WorkCentre 5024 Service Manual

06/2014
6-47
WC 5022/5024
6.3.8.2 NVM DRIVE & NOHAD
General
Version 1.0
6.3.8.2 NVM DRIVE & NOHAD
Table 1 NVM DRIVE & NOHAD
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value
Write Yes/
No
Initialization
Yes/No Description
740-001 DRV_MAIN_MOTOR_SPEED 1040000 1562000 1496201 Disabled Enabled main motor speed
(Unit: Ref CLK)
740-002 DRV_MAIN_MOTOR_BRAKE_SWITCH 0 1 0 Disabled Enabled Main motor brake signal switch
0: Main motor brake signal invaild1: Main motor brake sig-
nal effective
741-001 NOHAD_PRINT_STOP_DELAY 15 1800 15 Disabled Enabled The time for Fan high speed rotation after printing has
completed.
(Unit: 1 s)
741-002 NOHAD_STBY_MODE_INTVAL 1 20 1 Disabled Enabled The temperature sampling time for Fusing Fan Tempera-
ture Control.
(Unit: 1 s)
741-003 NOHAD_STBY_MODE_COUNT_THRESHOL
D
1 20 3 Disabled Enabled The threshold count for determining the mode transition of
the Fusing Fan Temperature Control.
(Unit: 1 time)
741-004 NOHAD_STBY_MODE_TEMP_THRESHOLD 0 800 245 Disabled Enabled The threshold temperature for determining the mode tran-
sition of the Fusing Fan Temperature Control.
(Unit: 0.1 Degrees Celsius)
741-005 NOHAD_STBY_MODE_SWITCH 0 1 1 Disabled Enabled Fusing Fan Temperature Control Execution Switch
0: Do not perform, 1: Perform
741-006 NOHAD_COLD_MODE_TEMP_THRESHOLD 0 300 140 Disabled Enabled The threshold temperature for determining the Fan Low
Temperature Stop Operation.
(Unit: 0.1 Degrees Celsius)
741-007 NOHAD_COLD_MODE_HOLD_TIME 0 180 0 Disabled Enabled The time to maintain the Fan in low speed rotation for Fan
Low Temperature Stop Operation.
(Unit: 1 s)
741-026 NOHAD_CONDENSE_SWITCH 0 1 0 Disabled Enabled Condensation Mode Execution Switch.
0: Do not perform, 1: Perform
741-027 NOHAD_CONDENSE_ENTRY_TEMP_THRE
SHOLD
0 300 120 Disabled Enabled The threshold temperature for determining whether to tran-
sition to the Condensation Mode.
(Unit: 0.1 Degrees Celsius)
741-028 NOHAD_CONDENSE_HOLD_TIME 0 240 90 Disabled Enabled The time where the transition to the Sleep Mode is prohib-
ited after entering the Condensation Mode.
(Unit: min)
741-029 NOHAD_SMELL_FILTER_SWITCH 0 1 0 Disabled Enabled Deodorant Filter Availability Switch.
0: No Deodorant Filter, 1: Deodorant Filter available
741-031 NOHAD_FAN_FAIL_START_TIMER 0 60 6 Disabled Enabled The time where Fail Detection is prohibited after the Fan
operation.
(Unit: 1 s)
741-032 NOHAD_FAN_FAIL_SUMPLE_TIME_THRES
HOLD
10 300 48 Disabled Enabled Fan Fail Signal Accumulated Time.
(Unit: 1 s)

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
