Xerox WorkCentre 5024 Service Manual

06/2014
6-57
WC 5022/5024
6.3.11.2 NVM X’fer
General
Version 1.0
6.3.11.2 NVM X’fer
Table 1 NVM X'fer
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value
Write Yes/
No
Initializatio
n Yes/No Description
745-016 XERO_TEMP_DATA -20 60 18 Enabled Enabled Stores the temperature detection result.
(Unit: 1 Degrees Celsius)
745-026 XERO_BTR_OUTPUT_SIDE1_BIAS 0 200 80 Enabled Enabled Stores the BTR Output (Side 1)
(Unit: 0.1 MicroAmp)
745-027 XERO_BTR_OUTPUT_SIDE2_BIAS 0 200 80 Enabled Enabled Stores the BTR Output (Side 2)
(Unit: 0.1 MicroAmp)
745-028 XERO_BTR_NET_OUTPUT_SIDE1_BIAS 0 200 80 Enabled Enabled Stores the BTR Final Output (for Side 1)
(Unit: 0.1 MicroAmp)
745-029 XERO_BTR_NET_OUTPUT_SIDE2_BIAS 0 200 80 Enabled Enabled Stores the BTR Final Output (for Side 2)
(Unit: 0.1 MicroAmp)
745-030 XERO_BTR_CORR_COEF_PLAIN_SIDE1 0 200 100 Disabled Enabled BTR Output Correction Coefficient (for Plain Side 1)
(Unit: %)
745-031 XERO_BTR_CORR_COEF_PLAIN_SIDE2 0 200 100 Disabled Enabled BTR Output Correction Coefficient (for Plain Side 2)
(Unit: %)
745-032 XERO_BTR_CORR_COEF_HEAVY1_SIDE1 0 200 100 Disabled Enabled BTR Output Correction Coefficient (for Heavyweight Side 1)
(Unit: %)
745-033 XERO_BTR_CORR_COEF_HEAVY1_SIDE2 0 200 100 Disabled Enabled BTR Output Correction Coefficient (for Heavyweight Side 2)
(Unit: %)
745-034 XERO_BTR_CORR_COEF_HEAVY2_SIDE1 0 200 100 Disabled Enabled BTR Output Correction Coefficient (for Extra Heavyweight
Side 1)
(Unit: %)
745-035 XERO_BTR_CORR_COEF_HEAVY2_SIDE2 0 200 100 Disabled Enabled BTR Output Correction Coefficient (for Extra Heavyweight
Side 2)
(Unit: %)
745-036 XERO_BTR_CORR_COEF_OHP_SIDE1 0 200 100 Disabled Enabled BTR Output Correction Coefficient (for Transparency)
(Unit: %)
745-037 XERO_BTR_CORR_COEF_LABEL_SIDE1 0 200 100 Disabled Enabled BTR Output Correction Coefficient (for Labels)
(Unit: %)

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
