ELEC
CHECKING THE SWITCHES
8-4
EAS00731
CHECKING THE SWITCHES
Check each switch for damage or wear, proper
connections, and also for continuity between the
terminals. Refer to “CHECKING SWITCH CON-
TINUITY”.
Damage/wear

Repair or replace.
Improperly connected

Properly connect.
Incorrect continuity reading

Replace the
switch.
OFF
PUSH
P
B
HI
LO
G
L
Y
G
L/R
Y
Br
Ch
Dg
/
W
P
B
L
N
R
Br
Ch
Dg
/
W
LOCK
OPEN
OFF
CHECK
ON
G/Y
Br RB
B
R
G
Br
Y
/
B
W
/
OFF
START
B
L
/
W









TOP VIEW
SIDE VIEW
 Horn switch
 Dimmer switch
 Turn signal switch
 Front brake switch
 Rear brake switch
 Star switch
 Main switch
 Fuse
 Oil level switch
