ENG
ENGINE ASSEMBLY AND ADJUSTMENT
4-27
EAS00419
TRANSMISSION
9 Nm (0.9 m • kg)
Circlip
Bearing
Oil seal
Drive axle
Bearing
Main axle
Conical spring washer
Flat washer
Secondary sheave axle
Bearing
Dowel pin
Gasket
Transmission case cover
Bearing
Oil seal
