ENG
ENGINE ASSEMBLY AND ADJUSTMENT
4-32
EAS00338
KICKSTARTER
10 Nm (1.0 m • kg)
Kick shaft
Return spring
Collar
Flat washer
Circlip
Kick crank
Kick pinion gear clip
Kick pinion gear
150 ~ 250 g
