Yamaha CS50 User Manual

ELEC
SIGNALING SYSTEM
8-27
EAS00793
SIGNALING SYSTEM
CIRCUIT DIAGRAM
 Main switch
 Fuse
 Battery

13 Front brake switch

14 Rear brake switch

15 Tail/brake light

18 Turn signal relay

19 Turn signal switch

20 Front turn signal light (left)

21 Front turn signal light (right)

22 Rear turn signal light (left)

23 Rear turn signal light (right)

26 Horn

27 Horn switch

28 Fuel sender

29 Thermo switch (CS50Z only)

30 Engine oil level switch

31 Water temperature warning light
(CS50Z only)

32 Fuel meter

33 Right turn signal indicator light

34 Left turn signal indicator light

36 Oil level warning light

38 Clock

39 Speedometer

40 Speed sensor

Yamaha CS50 Specifications

General

Fuel Capacity	4.5 liters
Fuel System	Carburetor
Cooling	Air-cooled
Transmission	Automatic
Starting System	Kick start
Brakes	Drum brakes (front and rear)
