Yamaha CS50 - Removing the Kickstarter System

ENG
ENGINE DISASSEMBLY
4-4
2. Remove:
• piston pin 
• piston 
• piston pin bearing 
CAUTION:
Do not use a hammer to take out the piston
pin.
REMOVING THE KICKSTARTER SYSTEM
1. Remove:
• clamp (air filter)
• air filter
2. Remove:
• oil hose delivery 
• carburator
3. Remove:
• kick crank
• crankcase cover  (left)
4. Remove:
• kick pinion gear 
NOTE:
When the kick pinion gear removed, move the
pedal axle.
5. Unhook:
• return spring 

