CHK
ADJ
FRONT COWLING AND FOOTREST
3-5
5. Remove:
• legshield
NOTE:
Remove first the main switch cover
6. Remove:
• hook bracket
7. Remove:
• footrest
INSTALLATION
Reverse the removal process
NOTE:
After installing all plastic parts, check that all
hooks are properly attached.
