ENG
ENGINE ASSEMBLY AND ADJUSTMENT
4-29
STARTER SYSTEM
8 Nm (0.8 m • kg)
13 Nm (1.3 m • kg)
Collar
Starter wheel gear
Bearing
Starter clutch
Plate
Shaft
Flat washer
Idle gear
O-ring
Starter motor
