Yamaha CS50 User Manual

ELEC
LIGHTING SYSTEM
8-26
• Set the main switch to “ON”.
• Start the engine.
• Measure the voltage (DC 12 V) of blue  on
the position light coupler (positionlight
side).
• Is the voltage within specification?
Wiring circuit from
the main switch
to the position light
coupler is faulty
and must be
repaired.
This circuit is OK.
YES
NO

Yamaha CS50 Specifications

General

Fuel Capacity	4.5 liters
Fuel System	Carburetor
Cooling	Air-cooled
Transmission	Automatic
Starting System	Kick start
Brakes	Drum brakes (front and rear)
