YASKAWA MP2100 Series User Manual

6.4 Registers
6-23
6
(3) Register Ranges in Programs
The programs and register ranges are shown below.
FUNC-000（関数）
プログラム
Max. 1000ステップ
関数個別レジスタ
関数入力レジスタ 17ワード
(XB,XW,XL,XFnnnnn)
関数出力レジスタ 17ワード
(YB,YW,YL,YFnnnnn)
関数内部レジスタ 64ワード
(ZB,ZW,ZL,ZFnnnnn)
定数データ Max.16384ワード
(#B,#W,#L,#Fnnnnn)
個別データ Max.16384ワード
(DB,DW,DL,DFnnnnn)
DWG H03（図面）
プログラム
Max. 1000ステップ
DWG個別レジスタ
定数データ Max.16384ワード
(#B,#W,#L,#Fnnnnn)
個別データ Max.16384ワード
(DB,DW,DL,DFnnnnn)
システムレジスタ
(SB,SW,SL,SFnnnnn)
DWG共通レジスタ
データレジスタ
(MB,MW,ML,MFnnnnn)
入力レジスタ
(IB,IW,IL,IFnnnnn)
出力レジスタ
(OB,OW,OL,OFnnnnn)
定数レジスタ
(CB,CW,CL,CFnnnnn)
FUNC-000（関数）
①
②
③
①
④
①：DWG共通レジスタは，どの図面，関数からも参照できます。
②：DWG個別レジスタはその図面内でのみ参照できます。
③：関数個別レジスタはその関数内でのみ参照できます。
④：関数からは関数外部レジスタを用いて，DWG共通レジスタ及びDWG個別レジスタを参照できます。
DWG H03 (Drawing)
Program
1,000 steps max.
Registers for individual
drawings
Constant data. 16,384 words
max. (#B, #W, #L, #Fnnnnn)
Individual data. 16,384 words
max. (DB, DW, DL, DFnnnnn)
Registers common to all drawings
System registers
Data registers
Input registers
(IB,IW,IL,IFhhhh)
Output registers
(OB,OW,OL,OFhhhh)
Constant registers
FUNC-000 (Function)
Program
1,000 steps max.
Registers for individual
functions
Function Input registers 17 words
(XB, XW, XL, XFnnnnn)
Function output registers 17 words
(YB, YW, YL, YFnnnnn)
Internal function registers 64
words (ZB, ZW, ZL, ZFnnnnn)
Constant data. 16,384 words max.
(#B, #W, #L, #Fnnnnn)
Individual data. 16,384 words
max. (DB, DW, DL, DFnnnnn)
External function
registers
(AB, AW, AL,
AFnnnnn)
①
Registers that are common to all drawings can be called from any drawing or function.
②
Registers that are unique to each drawing can be called only from within that drawing.
③
Registers that are unique to each function can be called only from within that function.
④
Registers that are common to all drawings and registers that are unique to each drawing can
①
Registers that are common to all drawings can be called from any drawing or function.
②
Registers that are unique to each drawing can be called only from within that drawing.
③
Registers that are unique to each function can be called only from within that function.
④
Registers that are common to all drawings and registers that are unique to each drawing can
be called from a function using the external function registers.
