3.1.9 Starting the MPE720
This section describes the preparation for connecting the MPE720 to the MP2100 and the method for installing
the sample program for the MP2100.
(1) MPE720 Startup Procedure
Make sure the MPE720 System Software is installed in advance. Refer to the Machine Controller MP900/
MP2000 Series MPE720 Software for Programming Device User's Manual (manual number: SIEPC88070005)
for the MPE installation method. The startup procedure is shown below.
1. Starting the MPE720
Start the MPE720.
2. Communication Settings
Define the communications with the MP2100.
3. Creating a Group Folder
Create a Group Folder.
4. Creating an Order Folder
Create an Order Folder.
5. Creating a Controller Folder
Create a Controller Folder.
6. Logging on Online
Log on to the MP2100.
7. Loading the Sample Program
Load the sample program from the MPE720 system CD-ROM to MPE720.
8. Transferring the Sample Program
Transfer the sample program individually from MPE720 to MP2100.
9. Setting Parameters
Set the individual parameters to match the sample program.
10. Saving to Flash Memory
Save the sample program to flash memory in the MP2100.
11. All Program File Group Dump
Backup the MP2100 data to the computer hard disk.
