7.3 Example of Setting Motion Parameters for the Machine
7-49
7
Use incremental addition mode for an infinite length axis. In other words, the new moving amount (an incremental moving
amount) is added to the previous position reference in OL

1C and set as the new position reference in OL

1C.
It is important to note that the position reference is not necessarily set between 0 and one less than the Maximum Value of
Rotary Counter (POSMAX).
Position Refer-
ence Type
Merits Demerits
Incremental addi-
tion mode
It is not necessary to consider the relationship
between OL

1C and the current position
when canceling a move. Incremental addition
mode can be used for finite or infinite length axis
type.
OL

1C does not necessarily equal the coordi-
nate value of the target position, so the position
reference can be difficult to understand intu-
itively.
Absolute mode The coordinate of the target position is specified
directly, making it easy to understand intuitively.
The current position must be set in OL

1C
whenever the power supply is turned ON or a
move is canceled. If this is not done, the axis
may move suddenly when a move command is
started.
Absolute mode cannot be used for an infinite
length axis type.
INFO
To Next Page
