13.2 System Errors
13-13
13
(3) Ladder Program User Operation Error Status
The following tables list data available when a user operation error occurs in a ladder program.
Table 13.1 Ladder Program User Operation Error Status - 1
Name Register No. Contents
DWG.A Error Count
Error Code
SW00080
Operation error code:
See Table 13.3.
Error code when an index error occurs:
See Table 13.4.
SW00081
DWG.I Error Count
Error Code
SW00082
SW00083
DWG.H Error Count
Error Code
SW00084
SW00085
Reserved by System
SW00086
SW00087
DWG.L Error Count
Error Code
SW00088
SW00089
Table 13.2 Ladder Program User Operation Error Status - 2
Name
Register No.
Remarks
DWG.A DWG.I DWG.H DWG.L
Error Count
SW00110 SW00126 SW00142 SW00174
Error DWG number
Parent drawing: FFFFH
Child drawing:
00H (H
: Child
drawing no.)
Grandchild drawing:
yyH (Hyy:
Grandchild drawing no.)
Function: 0100H
Function Calling DWG Number:
Number of the drawing that calls the
function in which an error occurred.
Function Calling DWG Step Number:
Step number of the drawing that calls
the function in which an error occurred.
This will be “0" if the error occurred
inside the drawing.
Error Code
SW00111 SW00127 SW00143 SW00175
Error A Register
SW00112 SW00128 SW00144 SW00176
SW00113 SW00129 SW00145 SW00177
Modification A
Register
SW00114 SW00130 SW00146 SW00178
SW00115 SW00131 SW00147 SW00179
Error F Register
SW00116 SW00132 SW00148 SW00180
SW00117 SW00133 SW00149 SW00181
Modification F
Register
SW00118 SW00134 SW00150 SW00182
SW00119 SW00135 SW00151 SW00183
Address Generating
Error
SW00120 SW00136 SW00152 SW00184
SW00121 SW00137 SW00153 SW00185
Error DWG Number
SW00122 SW00138 SW00154 SW00186
Function Calling
DWG Type
SW00123 SW00139 SW00155 SW00187
Function Calling
DWG Step Number
SW00124 SW00140 SW00156 SW00188
Reserved by System
SW00125 SW00141 SW00157 SW00189
