• When using the drive in common DC bus applications and the internal braking unit is not installed.
Enabling L8-55 under such conditions can incorrectly trigger a braking resistor fault (rF).
Setting 1: Enabled
Enable L8-55 when connecting a braking resistor or a braking resistor unit to the drive built-in braking transistor.
Models 2A0004 to 2A0138, 4A0002 to 4A0072, and 5A0003 to 5A0052 come with a built-in braking transistor.
n
L8-78: Power Unit Output Phase Loss Protection
Protects the power unit from phase loss.
Note: This parameter is only available in models 4A0930 and 4A1200.
No. Name Setting Range Default
L8-78 Power Unit Output Phase Loss Protection 0, 1 1
Setting 0: Disabled
Setting 1: Enabled
n
L8-93: LSo Detection Time at Low Speed
Sets the amount of time until baseblock is executed after LSo has been detected at low speed.
A setting of 0.0 s disables this parameter.
No. Name Setting Range Default
L8-93 LSo Detection Time at Low Speed 0.0 to 10.0 s 1.0 s
n
L8-94: LSo Detection Level at Low Speed
Determines the detection level of STo at low speed. Set as a percentage of the maximum frequency (E1-04).
No. Name Setting Range Default
L8-94 LSo Detection Level at Low Speed 0 to 10% 3%
n
L8-95: Average LSo Frequency at Low Speed
Sets the average number of times LSo can occur at low speed.
No. Name Setting Range Default
L8-95 Average LSo Frequency at Low Speed 1 to 50 times 10 times
5.8 L: Protection Functions
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
263
5
Parameter Details

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
