YASKAWA P1000

Digital
Operator
Display
Name
Minor Fault
Output
(H2-oo = 10)
Page
THo
<2>
Thermistor Disconnect YES 317
TIE Time Interval Error YES 307
TrPC IGBT Maintenance Time (90%) YES 317
UL6 Motor Underload YES 308
Uv Undervoltage YES 317
Digital
Operator
Display
Name
Minor Fault
Output
(H2-oo = 10)
Page
wRUn Run Delay Timer is Active YES 317
1PH
1-Phase
Foldback
<0x5A>
Single Phase Foldback – 317
<1>
Output when H2-oo = 2F.
<2> Detected in models 4A0930 and 4A1200.
n
Operation Errors
Table 6.6 Operation Error Displays
Digital
Operator
Display
Name Page
oPE01 Drive Unit Setting Error 319
oPE02 Parameter Setting Range Error 319
oPE03 Multi-Function Input Setting Error 319
oPE04 Terminal Board Mismatch Error 320
oPE05 Run Command Selection Error 320
oPE07 Multi-Function Analog Input Selection Error 320
Digital
Operator
Display
Name Page
oPE09 PID Control Selection Error 321
oPE10 V/f Data Setting Error 321
oPE11 Carrier Frequency Setting Error 321
oPE13 Pulse Train Monitor Selection Error 321
oPE28 Sequence Timer Error 321
n
Auto-Tuning Errors
Table 6.7 Auto-Tuning Error Displays
Digital
Operator
Display
Name Page
End1 Excessive V/f Setting 322
End2 Motor Iron Core Saturation Coefficient Error 322
End3 Rated Current Setting Alarm 322
End4 Adjusted Slip Value Fell Below Lower Limit 322
End5 Resistance Between Lines Error 322
End6 Leakage Inductance Alarm 322
End7 No-Load Current Alarm 323
Er-01 Motor Data Error 323
Er-02 Alarm 323
Digital
Operator
Display
Name Page
Er-03 STOP Button Input 323
Er-04 Line-to-Line Resistance Error 323
Er-05 No-Load Current Error 323
Er-08 Rated Slip Error 324
Er-09 Acceleration Error 324
Er-11 Motor Speed Error 324
Er-12 Current Detection Error 324
Er-13 Leakage Inductance Error 324
Er-17 Reverse Prohibited Error 324
n
Errors and Displays When Using the Copy Function
Table 6.8 Copy Errors
Digital
Operator
Display
Name Page
CoPy Writing parameter settings (flashing) 325
CPyE Error writing data 325
CSEr Copy unit error 325
dFPS Drive model mismatch 325
End Task complete 325
iFEr Communication error 325
Digital
Operator
Display
Name Page
ndAT Model, voltage class, capacity mismatch 325
rdEr Error reading data 326
rEAd Reading parameter settings (flashing) 326
vAEr Voltage class, capacity mismatch 326
vFyE Parameter setting mismatch 326
vrFy Comparing parameter settings (flashing) 326
6.3 Drive Alarms, Faults, and Errors
294
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
