YASKAWA P1000

Drive Model
Without Additional Impedance
With Additional Impedance
(use either DC type or AC type)
Yaskawa Reactor Part Number
Motor Power
(HP)
Drive Input
Current (A)
Motor Power
(HP)
Drive Input
Current (A)
DC Type AC Type
2A0110 10 60
DC Link Choke Built-in Do Not Use AC Reactor
10 60
2A0138 15 87 15 87
2A0169 20 114 20 114
2A0211 25 141 25 141
2A0250 30 167 30 167
2A0312 40 219 40 219
2A0360 50 273 50 273
2A0415 60 322 60 322
Table A.14 480 V Single-Phase Input (-5% to +10%), 460 V Three-Phase Motor
Drive Model
Without Additional Impedance
With Additional Impedance
(use either DC type or AC type)
Yaskawa Reactor Part Number
Motor Power
(HP)
Drive Input
Current (A)
Motor Power
(HP)
Drive Input
Current (A)
DC Type AC Type
4A0002 1/3 2.4 URX000041 URX000295 1/2 2.1
4A0004 3/4 4.2 URX000041 URX000299 1 3.8
4A0005 1 5.1 05P00620-0110 URX000303 1.5 5.5
4A0007 1.5 7.5 05P00652-0213 URX000308 2 6.7
4A0009 2 10 URX000048 URX000312 3 9.5
4A0011 2 10 URX000053 URX000316 3 10
4A0018 3 13.2 URX000052 URX000316 3 10
4A0023 3 14 URX000052 URX000316 5 15
4A0031 7.5 30.2 URX000055 URX000324 7.5 22
4A0038 7.5 31 05P00620-0123 URX000327 10 31
4A0044 10 38.3 URX000061 URX000327 10 28
4A0058 15 42.2
DC Link Choke Built-in
URX000332 15 41
4A0072 20 55
Do Not Use AC Reactor
20 56
4A0088 20 56 20 56
4A0103 20 57 URX000335 20 54
4A0139 40 108 URX000341 40 104
4A0165 40 110 URX000341 40 104
4A0208 50 136 URX000347 50 130
4A0250 60 162 URX000347 60 154
4A0296 60 165 URX000350 75 192
4A0362 75 205 URX000353 100 251
4A0414 125 328 URX000356 125 314
4A0515 125 337 URX000353 125 314
4A0675 150 405 Do Not Use 150 405
A.4 Drive Derating Data
