Table A.15 600 V Single-Phase Input (-5% to +10%), 575 V Three-Phase Motor
Drive Model
Without Additional Impedance
With Additional Impedance
(use either DC type or AC type)
Yaskawa Reactor Part Number
Motor Power
(HP)
Drive Input
Current (A)
Motor Power
(HP)
Drive Input
Current (A)
DC Type AC Type
5A0003 1 3.5 05P00620-0110 URX000303 1 3.5
5A0004 1.5 4.8 URX000044 URX000306 2 5
5A0006 2 7 05P00652-0213 URX000308 3 7.6
5A0009 3 9.5 URX000049 URX000313 5 11
5A0011 2 7.1 05P00652-0213 URX000308 3 7.7
5A0017 5 16 URX000048 URX000316 5 12
5A0022 5 16 URX000053 URX000320 7.5 18
5A0027 7.5 24 URX000055 URX000324 10 23
5A0032 7.5 24 URX000055 URX000324 10 23
5A0041 15 34
DC Link Choke Built-in
URX000326 15 32
5A0052 15 34 URX000326 15 32
5A0062 25 57 URX000335 25 54
5A0077 30 66 URX000338 30 64
5A0099 30 66 URX000338 30 64
5A0125 50 106 URX000344 50 102
5A0145 50 106 URX000344 50 102
5A0192 75 159 URX000347 75 152
5A0242 75 159 URX000347 75 152
n
Single-Phase Main Circuit Wiring and Tightening Torques
Table A.16 240 V Single-Phase Main Circuit Wiring and Tightening Torques
Drive Model Terminal
Recomm.
Gauge Without
Additional
Impedance
<1>
AWG, kcmil
Recomm.
Gauge With
Additional
Impedance
<2>
AWG, kcmil
Wire Range
AWG, kcmil
<3>
Screw
Size
Tightening Torque
N·m (lb.in.)
2o0004
2o0006
2o0008
2o0010
2o0012
R/L1, S/L2 14 14 14 to 10
M4 1.2 to 1.5 (10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 14 to 10
⊖, ⊕1, ⊕2
- 14 14 to 10
B1, B2 - - 14 to 10
GND 14 14 14 to 10
2o0018
2o0021
R/L1, S/L2 10 10 14 to 10
M4 1.2 to 1.5 (10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 14 to 10
⊖, ⊕1, ⊕2
- 10 14 to 10
B1, B2 - - 14 to 10
GND 10 10 14 to 10
2o0030
R/L1, S/L2 10 10 12 to 6
M4 2.1 to 2.3 (18.6 to 20.4)
U/T1, V/T2, W/T3 12 12 12 to 6
⊖, ⊕1, ⊕2
- 10 12 to 6
B1, B2 - - 12 to 10
GND 10 10 12 to 10 M5 2.0 to 2.5 (17.7 to 22.1)
2o0040
R/L1, S/L2 10 8 12 to 6
M4 2.1 to 2.3 (18.6 to 20.4)
U/T1, V/T2, W/T3 12 12 12 to 6
⊖, ⊕1, ⊕2
- 8 12 to 6
B1, B2 - - 12 to 10
GND 10 8 12 to 10 M5 2 to 2.5 (17.7 to 22.1)
A.4 Drive Derating Data
