YASKAWA P1000

Drive Model Terminal
Recomm.
Gauge Without
Additional
Impedance
<1>
AWG, kcmil
Recomm.
Gauge With
Additional
Impedance
<2>
AWG, kcmil
Wire Range
AWG, kcmil
<3>
Screw
Size
Tightening Torque
N·m (lb.in.)
2o0056
R/L1, S/L2 4 6 6 to 4
M6 5.4 to 6.0 (47.8 to 53.1)
U/T1, V/T2, W/T3 6 6 6 to 4
⊖, ⊕1, ⊕2
- 6 6 to 4
B1, B2 - - 10 to 8 M5 2 to 2.5 (17.7 to 22.1)
GND 6 6 8 to 6 M6 5.4 to 6.0 (47.8 to 53.1)
2o0069
R/L1, S/L2 4 4 10 to 2
M8 9.9 to 11.0 (87.6 to 97.4)
U/T1, V/T2, W/T3 10 10 10 to 2
⊖, ⊕1, ⊕2
- 4 10 to 2
B1, B2 - - 10 to 6 M5 2 to 2.5 (17.7 to 22.1)
GND 6 6 6 to 4 M6 5.4 to 6.0 (47.8 to 53.1)
2o0081
R/L1, S/L2 3 3 10 to 2
M8 9.9 to 11.0 (87.6 to 97.4)
U/T1, V/T2, W/T3 10 8 10 to 2
⊖, ⊕1, ⊕2
- 3 10 to 2
B1, B2 - - 10 to 6 M5 2 to 2.5 (17.7 to 22.1)
GND 6 6 6 to 4 M6 5.4 to 6.0 (47.8 to 53.1)
2o0110
R/L1, S/L2 4 4 10 to 1/0
M8 9.9 to 11.0 (79.7 to 97.4)
U/T1, V/T2, W/T3 10 10 10 to 1/0
⊖, ⊕1
- - 10 to 1/0
B1, B2 - - 10 to 1/0
GND 6 6 10 to 1/0
2o0138
R/L1, S/L2 2 2 10 to 3/0
M10 18 to 23 (159 to 204)
U/T1, V/T2, W/T3 8 8 10 to 3/0
⊖, ⊕1
- - 10 to 3/0
B1, B2 - - 10 to 3/0
GND 6 6 10 to 1/0 M8 9 to 11 (79.7 to 97.4)
2o0169
R/L1, S/L2 1/0 6 10 to 4/0
M10 18 to 23 (159 to 204)
U/T1, V/T2, W/T3 1/0 6 10 to 4/0
⊖, ⊕1
- - 10 to 4/0
⊕3
- - 10 to 4/0
GND 3 3 10 to 4/0
2o0211
R/L1, S/L2 2/0 2/0 10 to 4/0
M10 18 to 23 (159 to 204)
U/T1, V/T2, W/T3 1/0 1/0 10 to 4/0
⊖, ⊕1
- - 10 to 4/0
⊕3
- - 10 to 4/0
GND 2 2 10 to 4/0
2o0250
R/L1, S/L2 3/0 4/0 up to 250 kcmil
M12 32 to 40 (283 to 354)
U/T1, V/T2, W/T3 3 3 up to 250 kcmil
⊖, ⊕1
- - up to 250 kcmil
⊕3
- - up to 250 kcmil M10 18 to 23 (159 to 204)
GND 1 1/0 up to 250 kcmil M12 32 to 40 (283 to 354)
2o0312
R/L1, S/L2 1/0 X 2P 1/0 X 2P up to 250 kcmil
M12 32 to 40 (283 to 354)
U/T1, V/T2, W/T3 1 1 up to 250 kcmil
⊖, ⊕1
- - up to 250 kcmil
⊕3
- - up to 250 kcmil M10 18 to 23 (159 to 204)
GND 3/0 3/0 up to 250 kcmil M12 32 to 40 (283 to 354)
A.4 Drive Derating Data
