YASKAWA P1000

Drive Model Terminal
Recomm.
Gauge Without
Additional
Impedance
<1>
AWG, kcmil
Recomm.
Gauge With
Additional
Impedance
<2>
AWG, kcmil
Wire Range
AWG, kcmil
<3>
Screw
Size
Tightening Torque
N·m (lb.in.)
4o0044
R/L1, S/L2 6 6 6 to 4
M6 5.4 to 6.0 (47.8 to 53.1)
U/T1, V/T2, W/T3 6 6 6 to 4
⊖, ⊕1, ⊕2
- 6 6 to 4
B1, B2 - - 10 to 8 M5 2.7 to 3.0 (23.9 to 26.6)
GND 6 6 8 to 6 M6 5.4 to 6.0 (47.8 to 53.1)
4o0058
R/L1, S/L2 8 8 10 to 1/0
M8 9 to 11 (79.7 to 97.4)
U/T1, V/T2, W/T3 10 10 10 to 1/0
⊖, ⊕1, ⊕2
- - 10 to 1/0
B1, B2 - - 10 to 1/0
GND 8 8 10 to 1/0
4o0072
R/L1, S/L2 4 4 10 to 1/0
M8 9 to 11 (79.7 to 97.4)
U/T1, V/T2, W/T3 10 10 10 to 1/0
⊖, ⊕1, ⊕2
- - 10 to 1/0
B1, B2 - - 10 to 1/0
GND 6 6 10 to 1/0
4o0088
R/L1, S/L2 4 4 6 to 250 kcmil
M8 9 to 11 (79.7 to 97.4)
U/T1, V/T2, W/T3 6 6 6 to 250 kcmil
⊖, ⊕1
- - 6 to 250 kcmil
⊕3
- - 6 to 250 kcmil
GND 6 6 6 to 250 kcmil
4o0103
R/L1, S/L2 4 6 6 to 250 kcmil
M8 9 to 11 (79.7 to 97.4)
U/T1, V/T2, W/T3 6 6 6 to 250 kcmil
⊖, ⊕1
- - 6 to 250 kcmil
⊕3
- - 6 to 250 kcmil
GND 6 6 6 to 250 kcmil
4o0139
R/L1, S/L2 1 1 10 to 4/0
M10 18 to 23 (159 to 204)
U/T1, V/T2, W/T3 6 6 10 to 4/0
⊖, ⊕1
- - 10 to 4/0
⊕3
- - 10 to 4/0
GND 4 4 10 to 4/0
4o0165
R/L1, S/L2 1/0 1 10 to 4/0
M10 18 to 23 (159 to 204)
U/T1, V/T2, W/T3 6 6 10 to 4/0
⊖, ⊕1
- - 10 to 4/0
⊕3
- - 10 to 4/0
GND 3 4 10 to 4/0
4o0208
R/L1, S/L2 2/0 2/0 up to 250 kcmil
M10 18 to 23 (159 to 204)
U/T1, V/T2, W/T3 4 4 up to 250 kcmil
⊖, ⊕1
- - up to 250 kcmil
⊕3
- - up to 250 kcmil
GND 2 2 up to 250 kcmil
4o0250
R/L1, S/L2 3/0 3/0 up to 250 kcmil
M10 18 to 23 (159 to 204)
U/T1, V/T2, W/T3 3 3 up to 250 kcmil
⊖, ⊕1
- - up to 250 kcmil
⊕3
- - up to 250 kcmil
GND 1 1 up to 250 kcmil
A.4 Drive Derating Data
412
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
