Drive Model Terminal
Recomm.
Gauge Without
Additional
Impedance
AWG, kcmil
Screw
Size
Panduit Ring Terminal
(non-insulated)
Panduit
Recomm.
Installation
Tool
Panduit
Crimphead /
Die Part No.
Insulation Cap
Model No.
2o0415
R/L1, S/L2 3/0 X 2P
M12
S3/0-12R-5 (Qty. 2)
CT-720 CD-720-2
TP-080 (Qty. 2)
U/T1, V/T2, W/T3 3/0 S3/0-12R-5 TP-080
Table A.20 JST Closed-Loop Crimp Terminal Size Single-Phase w/o Additional Impedance
Drive Model Terminal
Recomm.
Gauge Without
Additional
Impedance
AWG, kcmil
Screw
Size
JST Ring Terminal
(non-insulated)
JST
Recomm.
Installation
Tool
JST
Crimphead /
Die Part No.
Insulation Cap
Model No.
2o0004
2o0006
2o0008
2o0010
2o0012
R/L1, S/L2 14
M4 R2-4 YA-4 AD-900 TP-003
U/T1, V/T2, W/T3 14
2o0018
2o0021
R/L1, S/L2 10
M4
R5.5-4
YA-4 AD-900
TP-005
U/T1, V/T2, W/T3 14 R2-4 TP-003
2o0030
R/L1, S/L2 10
M4 R5.5-4 YA-4 AD-900 TP-005
U/T1, V/T2, W/T3 12
2o0040
R/L1, S/L2 10
M4 R5.5-4 YA-4 AD-900 TP-005
U/T1, V/T2, W/T3 12
2o0056
R/L1, S/L2 4
M6
R22-6
YA-5
AD-953 TP-022
U/T1, V/T2, W/T3 6 R14-6 AD-952 TP-014
2o0069
R/L1, S/L2 4
M8
R22-8 YA-5 AD-953 TP-022
U/T1, V/T2, W/T3 10 R5.5-8 YA-4 AD-900 TP-005
2o0081
R/L1, S/L2 3
M8
R38-8 YA-5 AD-954 TP-038
U/T1, V/T2, W/T3 10 R5.5-8 YA-4 AD-900 TP-005
2o0110
R/L1, S/L2 4
M8
R22-8 YA-5 AD-953 TP-022
U/T1, V/T2, W/T3 10 R5.5-8 YA-4 AD-900 TP-005
2o0138
R/L1, S/L2 2
M10
R38-10
YA-5
AD-954 TP-038
U/T1, V/T2, W/T3 8 R8-10 AD-951 TP-008
2o0169
R/L1, S/L2 1/0
M10
R60-10
YA-5
AD-955 TP-060
U/T1, V/T2, W/T3 6 R14-10 AD-952 TP-014
2o0211
R/L1, S/L2 2/0
M10
70-10
YF-1
YET-300-1
TD-323,
TD-312
TP-080
U/T1, V/T2, W/T3 1/0 R60-10 YA-5 AD-955 TP-060
2o0250
R/L1, S/L2 3/0
M12
80-L12
YF-1
YET-300-1
TD-323,
TD-312
TP-080
U/T1, V/T2, W/T3 3 R38-12 YA-5 AD-954 TP-038
2o0312
R/L1, S/L2 1/0 X 2P
M12
R60-14 (Qty. 2)
YA-5
AD-955 TP-060 (Qty. 2)
U/T1, V/T2, W/T3 1 R38-14 AD-954 TP-038
2o0360
R/L1, S/L2 2/0 X 2P
M12
70-14 (Qty. 2)
YF-1
YET-300-1
TD-323,
TD-312
TP-080 (Qty. 2)
U/T1, V/T2, W/T3 2/0 70-14 TP-080
2o0415
R/L1, S/L2 3/0 X 2P
M12
80-L12 (Qty. 2)
YF-1
YET-300-1
TD-323
TD-312
TP-080 (Qty. 2)
U/T1, V/T2, W/T3 3/0 80-L12 TP-080
