YASKAWA P1000

n
Three-Phase AC 400 V Models 4A0515A, 4A0675A
B
A
C
D
F
G
H
E
I
J
K
L
M
N
N
O
P
A – Circuit board cooling fan
B – Cooling fan
C – Fan bracket
D – Circulation Fan
E – Digital operator
F – Drive cover 1
G – Drive cover 2
H – Terminal cover
I – USB port (type-B)
J – Front cover screw
K – Front cover
L – Circuit board cooling fan unit case
M – Terminal board
N – Mounting hole
O – Heatsink
P – Fan guard
Figure 1.8 Exploded view of IP00/Open Type Enclosure Components (Model 4A0675A)
1.5 Component Names
