YASKAWA P1000

No. Name Unit Default Settings
–
Model CIMR-Po
– 4A0072 4A0088 4A0103 4A0139
o2-04 Drive Model Selection Hex. A1 A2 A3 A4
E2-11 Motor rated power kW (HP)
37
(50)
45
(60)
55
(75)
75
(100)
b3-04 V/f Gain during Speed Search % 100 100 80 60
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5 0.7
b3-07
Output Current 2 during Speed Search
(Speed Estimation Type)
– – – – –
b3-26 Start Speed Search Select – – – – –
b8-03 Energy Saving Control Filter Time Constant s 0.50 0.50 2.00 2.00
b8-04 Energy Saving Coefficient Value – 76.32 71.56 67.2 46.2
C5-17 Motor Inertia
kgm
2
0.273 0.333 0.490 0.90
C6-02 Carrier Frequency Selection – 7 7 7 7
E2-01 Motor Rated Current A 65.6 79.7 95 130
E2-02 Motor Rated Slip Hz 1.33 1.6 1.46 1.39
E2-03 Motor No-Load Current A 19.1 22 24 36
E2-05 Motor Line-to-Line Resistance Ω 0.155 0.122 0.088 0.092
E2-06 Motor Leakage Inductance % 18.8 19.9 20 20
E2-10 Motor Iron Loss for Torque Compensation W 925 1125 1260 1600
L2-02 Momentary Power Loss Ride-Thru Time s 2 2 2 2
L2-03 Momentary Power Loss Min. Basebl. Time s 1.1 1.2 1.2 1.3
L2-04 Momentary Power Loss Volt. Recov. Time s 0.6 0.6 1 1
L3-24 Motor Acceleration Time for Inertia Calculations s 0.32 0.387 0.317 0.533
L8-02 Overheat Alarm Level °C 120 110 120 130
L8-35 Installation Method Selection – 0 0 0 0
L8-38 Carrier Frequency Reduction Selection – 2 2 2 2
n1-03 Hunting Prevention Time Constant ms 10 10 10 30
B.16 Defaults by Drive Model
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
495
B
Parameter List
