YASKAWA P1000

No. Name Unit Default Settings
–
Model CIMR-Po
– 4A0165 4A0208 4A0250 4A0296
o2-04 Drive Model Selection Hex. A5 A6 A7 A8
E2-11 Motor rated power kW (HP)
90
(125)
110
(150)
132
(200)
160
(250)
b3-04 V/f Gain during Speed Search % 60 60 60 60
b3-06 Output Current 1 during Speed Search – 0.7 0.7 0.7 0.7
b3-07
Output Current 2 during Speed Search
(Speed Estimation Type)
– – – – –
b3-26 Start Speed Search Select – – – – –
b8-03 Energy Saving Control Filter Time Constant s 2.00 2.00 2.00 2.00
b8-04 Energy Saving Coefficient Value – 38.91 36.23 32.79 30.13
C5-17 Motor Inertia
kgm
2
1.10 1.90 2.10 3.30
C6-02 Carrier Frequency Selection – 7 7 7 7
E2-01 Motor Rated Current A 156 190 223 270
E2-02 Motor Rated Slip Hz 1.4 1.4 1.38 1.35
E2-03 Motor No-Load Current A 40 49 58 70
E2-05 Motor Line-to-Line Resistance Ω 0.056 0.046 0.035 0.029
E2-06 Motor Leakage Inductance % 20 20 20 20
E2-10 Motor Iron Loss for Torque Compensation W 1760 2150 2350 2850
L2-02 Momentary Power Loss Ride-Thru Time s 2 2 2 2
L2-03 Momentary Power Loss Min. Basebl. Time s 1.5 1.7 1.7 1.8
L2-04 Momentary Power Loss Volt. Recov. Time s 1 1 1 1
L3-24 Motor Acceleration Time for Inertia Calculations s 0.592 0.646 0.673 0.777
L8-02 Overheat Alarm Level °C 130 120 120 125
L8-35 Installation Method Selection – 0 0 0 0
L8-38 Carrier Frequency Reduction Selection – 2 2 2 2
n1-03 Hunting Prevention Time Constant ms 30 30 30 30
B.16 Defaults by Drive Model
496
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
