YASKAWA P1000 Technical Manual

No. Name Unit Default Settings
–
Model CIMR-Po
– 5A0077 5A0099
o2-04 Drive Model Selection Hex. D3 D4
E2-11 Motor Rated Power kW (HP)
55
(75)
75
(100)
b3-04 V/f Gain during Speed Search % 80 80
b3-06 Output Current 1 during Speed Search – 0.5 0.5
b3-07
Output Current 2 during Speed Search
(Speed Estimation Type)
– – –
b3-26 Start Speed Search Select – – –
b8-03 Energy Saving Control Filter Time Constant s 2 2
b8-04 Energy Saving Coefficient Value – 80.87 70.07
C5-17 Motor Inertia
kgm
2
0.490 0.90
C6-02 Carrier Frequency Selection – 7 7
E2-01 Motor Rated Current A 77 99
E2-02 Motor Rated Slip Hz 1.46 1.39
E2-03 Motor No-Load Current A 23.1 29.7
E2-05 Motor Line-to-Line Resistance Ω 0.15 0.099
E2-06 Motor Leakage Inductance % 20 20
E2-10 Motor Iron Loss for Torque Compensation W 1260 1600
L2-02 Momentary Power Loss Ride-Thru Time s 2 2
L2-03 Momentary Power Loss Minimum Baseblock Time s 1.8 1.8
L2-04 Momentary Power Loss Voltage Recovery Time s 1.5 1.6
L3-24 Motor Acceleration Time for Inertia Calculations s 0.317 0.533
L8-02 Overheat Alarm Level °C 110 110
L8-35 Installation Method Selection – 2 2
L8-38 Carrier Frequency Reduction Selection – 2 2
n1-03 Hunting Prevention Time Constant ms 10 30
B.16 Defaults by Drive Model
502
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
