YASKAWA P1000 Technical Manual

No. Name Unit Default Settings
–
Model CIMR-Po
– 5A0041 5A0052 5A0062
o2-04 Drive Model Selection Hex. CF D1 D2
E2-11 Motor Rated Power kW (HP)
30
(40)
37
(50)
45
(60)
b3-04 V/f Gain during Speed Search % 80 80 80
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5
b3-07
Output Current 2 during Speed Search
(Speed Estimation Type)
– – – –
b3-26 Start Speed Search Select – – – –
b8-03 Energy Saving Control Filter Time Constant s 0.5 0.5 0.5
b8-04 Energy Saving Coefficient Value – 115.57 97.01 90.07
C5-17 Motor Inertia
kgm
2
0.220 0.273 0.333
C6-02 Carrier Frequency Selection – 7 7 7
E2-01 Motor Rated Current A 41 52 62
E2-02 Motor Rated Slip Hz 1.8 1.33 1.6
E2-03 Motor No-Load Current A 12.3 15.6 18.8
E2-05 Motor Line-to-Line Resistance Ω 0.438 0.267 0.21
E2-06 Motor Leakage Inductance % 20.7 18.8 19.9
E2-10 Motor Iron Loss for Torque Compensation W 750 925 1125
L2-02 Momentary Power Loss Ride-Thru Time s 2 2 2
L2-03 Momentary Power Loss Minimum Baseblock Time s 1.2 1.2 1.5
L2-04 Momentary Power Loss Voltage Recovery Time s 1.1 1.2 1.3
L3-24 Motor Acceleration Time for Inertia Calculations s 0.323 0.32 0.387
L8-02 Overheat Alarm Level °C 110 110 110
L8-35 Installation Method Selection – 2 2 2
L8-38 Carrier Frequency Reduction Selection – 2 2 2
n1-03 Hunting Prevention Time Constant ms 10 10 10
B.16 Defaults by Drive Model
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
501
B
Parameter List

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
