YASKAWA P1000

Drive Model Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
N·m (lb.in.)
2A0250
R/L1, S/L2, T/L3 3/0 × 2P 3/0 to 300
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 3/0 × 2P 3/0 to 300
⊖, ⊕1
– 3/0 to 300
⊕3
– 2 to 300 M10
18 to 23
(159 to 204)
3 3 to 300 M12
32 to 40
(283 to 354)
2A0312
R/L1, S/L2, T/L3 4/0 × 2P 3/0 to 300
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 3/0 × 2P 3/0 to 300
⊖, ⊕1
– 3/0 to 300
⊕3
– 3/0 to 300 M10
18 to 23
(159 to 204)
2 2 to 300 M12
32 to 40
(283 to 354)
2A0360
R/L1, S/L2, T/L3 250 × 2P 4/0 to 600
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 4/0 × 2P 4/0 to 600
⊖, ⊕1
– 250 to 600
⊕3
– 3/0 to 600 M10
18 to 23
(159 to 204)
1 1 to 350 M12
32 to 40
(283 to 354)
2A0415
R/L1, S/L2, T/L3 350 × 2P 250 to 600
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 300 × 2P 300 to 600
⊖, ⊕1
– 300 to 600
⊕3
– 3/0 to 600 M10
18 to 23
(159 to 204)
1 1 to 350 M12
32 to 40
(283 to 354)
<1> Install a GFCI when using this wire gauge in accordance with IEC/EN 61800-5-1.
<2>
Install a GFCI, or use 10 mm
2
(AWG 8) copper wire when using this wire gauge in accordance with IEC/EN 61800-5-1.
Note: When connecting peripheral devices or options to terminals ⊖, ⊕1, ⊕3, B1, and B2, refer to the instruction manual for each device. For
more information, contact Yaskawa or your nearest sales representative.
n
Three-Phase 400 V Class
Table 3.4 Wire Gauge and Torque Specifications (Three-Phase 400 V Class)
Drive Model Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
N·m (lb.in.)
4A0002
4A0004
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
⊖, ⊕1, ⊕2
– 14 to 10
B1, B2 – 14 to 10
12
<1>
14 to 12
4A0005
4A0007
4A0009
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
⊖, ⊕1, ⊕2
– 14 to 10
B1, B2 – 14 to 10
10
<1>
14 to 10
4A0011
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
⊖, ⊕1, ⊕2
– 14 to 10
B1, B2 – 14 to 10
10
<1>
14 to 10
3.8 Main Circuit Wiring
YASKAWA SIEP YAIP1U 01C AC Drive - P1000 Technical Manual
87
3
Electrical Installation
