YASKAWA P1000

Drive Model Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
N·m (lb.in.)
4A0018
R/L1, S/L2, T/L3 10 12 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 10 12 to 6
⊖, ⊕1, ⊕2
– 12 to 6
B1, B2 – 12 to 10
10
<1>
14 to 10 M5
2.0 to 2.5
(17.7 to 22.1)
4A0023
R/L1, S/L2, T/L3 10 10 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 10 10 to 6
⊖, ⊕1, ⊕2
– 12 to 6
B1, B2 – 12 to 10
10
<1>
12 to 10 M5
2.0 to 2.5
(17.7 to 22.1)
4A0031
R/L1, S/L2, T/L3 8 8 to 6
M5
3.6 to 4.0
(31.8 to 35.4)
U/T1, V/T2, W/T3 8 10 to 6
⊖, ⊕1, ⊕2
– 10 to 6
B1, B2 – 10 to 8
2.7 to 3.0
(23.9 to 26.6)
8
<2>
10 to 8 M6
5.4 to 6.0
(47.8 to 53.1)
4A0038
R/L1, S/L2, T/L3 6 8 to 6
M5
3.6 to 4.0
(31.8 to 35.4)
U/T1, V/T2, W/T3 8 8 to 6
⊖, ⊕1, ⊕2
– 6
B1, B2 – 10 to 8
2.7 to 3.0
(23.9 to 26.6)
6 10 to 6 M6
5.4 to 6.0
(47.8 to 53.1)
4A0044
R/L1, S/L2, T/L3 6 6 to 4
M6
5.4 to 6.0
(47.8 to 53.1)
U/T1, V/T2, W/T3 6 6 to 4
⊖, ⊕1, ⊕2
– 6 to 4
B1, B2 – 10 to 8 M5
2.7 to 3.0
(23.9 to 26.6)
6 8 to 6 M6
5.4 to 6.0
(47.8 to 53.1)
4A0058
R/L1, S/L2, T/L3 4 6 to 4
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 4 6 to 4
⊖, ⊕1
– 6 to 1
B1, B2 – 8 to 4
6 8 to 6
4A0072
R/L1, S/L2, T/L3 3 4 to 3
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 3 4 to 3
⊖, ⊕1
– 4 to 1
B1, B2 – 6 to 3
6 6
4A0088
R/L1, S/L2, T/L3 2 3 to 1/0
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 2 3 to 1/0
⊖, ⊕1
– 3 to 1/0
⊕3
– 6 to 1/0
4 6 to 4
4A0103
R/L1, S/L2, T/L3 1/0 2 to 1/0
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 1 2 to 1/0
⊖, ⊕1
– 3 to 1/0
⊕3
– 4 to 1/0
4 6 to 4
3.8 Main Circuit Wiring
