R Series Service Manual

4-2 9650-0903-01 Rev. L

List of Replacement Parts

Item numbers refer to the diagrams beginning on page 4-11.

For the System Brick Assembly see page 4-41.

Part Number Description Item number

Main Housing

9310-2787-99 Rework, Main Housing 1

9301-0525-01 Assembly, PCB, PCB, Beeper Connector 19

9330-0750 Mount, Speaker, Beeper, Foam 18

9161-0034 Gasket, Beeper, Foam 17

9500-0760 Assembly, Cable, Paddle Shorting 12

9161-0025 Gasket, Printer, Flex Cable 4

9161-0026 Gasket, Battery Trough to Housing 2

9500-0746-01 Cable, Assembly, Beeper 16

9161-0302 Gasket, Paddle Latch 3

9320-0748 Panel, Connector, Ground Plane 10

9320-0751 Plane, Ground, Battery Board 11

0163-0401 Scr. PPH. #4.x 0.312". STL./ZNC.Hi/Lo 8

9161-0027 Gasket, Compact Flash to Housing 5

9330-0769 Pad, ESD, ECG Connector 14

9330-0756 Pad, ESD, Battery PCB 9

9330-0738 Pad, .70 X .50, rubber 6

9305-0903-01 Label, regulatory, UL, Large SN window 7

0140-0201 Ferrite Core Flat Cable Type 13
