R Series Service Manual
1-38 9650-0903-01 Rev. L
22.0NIBP Volume Leak Test
The volume leak test verifies the integrity of the pneumatic system on the R Series NIBP module. This test should be performed annually or every 10,000
readings, whichever comes first.
Tools Needed: NIBP simulator (the values and procedure provided in this manual are specific to the BP Pump 2)
Test Setup:
1. Connect the simulator hose to the NIBP connector on the R Series unit.
2. Configure the NIBP simulator for the volume leak test. For example, on the BP Pump 2:
• Press the MODE button three times to go into Tests mode.
• Press the SELECT button twice to access the volume leak test.
3. Make sure the ECG cable is not connected to the R Series unit.
4. If the SpO
2
option is installed, make sure that the SpO
2
patient cable is NOT connected to the R Series unit.
Do this... Observe this... Pass/Fail
22.1 Turn the Selector Switch to OFF.
After 10 seconds, press and hold the fourth
softkey from the left and turn the Selector
Switch to MONITOR (ON for AED units).
The R Series powers on in the NIBP Service Mode.
22.2 Press the Leak Test softkey. The R Series displays the NIBP Leak Test Screen.
22.3 On the NIBP simulator, set the pressure
parameter to 200 mmHg.
The NIBP simulator displays a pressure reading of 200 mmHg.
22.4
On the
R Series unit, press the Close Valves
softkey.
The Valves status changes from OPEN to CLOSED.
oo
To Next Page
