ZOLL R Series Service Manual

R Series Service Manual
9650-0903-01 Rev. L 1-19
9.0 Notch Filter Test
Tools Needed: Impulse 4000 (or equivalent).
Test Setup:
1. Connect the ECG cable to the Impulse 4000.
2. Connect the ECG cable to the unit.
Do this... Observe this... Pass/Fail/NA
9.1 Turn the selector switch to MONITOR mode (for
AED units turn to ON.)
9.2 Select lead I, size 3x.
Select 60Hz sine wave (or 50 Hz for a 50Hz
unit) on the Fluke 4000.
9.3 Press RECORDER button. Verify that the waveform amplitude on the strip chart is less than 1.5 mm.
ooo
9.4 Turn the unit off.
Record your results on the Maintenance Test Checklist.

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
