R Series Service Manual
1-16 9650-0903-01 Rev. L
6.0 Paddles Test
Tools Needed: None.
Test Setup: If applicable, connect the OneStep cable to the paddles and place the paddles in paddle wells.
Do this... Observe this... Pass/Fail/NA
6.1 Turn the selector switch to DEFIB (for AED
units, turn the selector switch to ON, and
select Manual Mode.) Press and hold the
ENERGY DOWN button on the sternum paddle.
The energy selection decreases to 1J.
ooo
6.2 Press and release the ENERGY UP button on
the sternum paddle for each setting.
Verify the energy levels increment through the following: 1-10, 15, 20, 30, 50,
75, 100, 120, 150, 200J.
ooo
6.3 Press and release the RECORDER button on
the sternum paddle.
The recorder turns on.
ooo
6.4 Press and release the RECORDER button
again.
Verify the recorder turns off.
ooo
6.5 Select 30J using the paddle ENERGY button.
Press the CHARGE button on the Apex paddle.
The unit charges to 30J, then the red LED charge indicator illuminates and the
charge tone sounds. (Note that the front panel shock button does not
illuminate).
ooo
6.6 Press and release the APEX SHOCK button. No discharge.
ooo
6.7 Press and release the STERNUM SHOCK
button.
No discharge.
ooo
6.8 Press and hold both paddles SHOCK buttons. The unit discharges. The 30J TEST OK message displays and the red LED
turns off. The recorder runs.
ooo
Record your results on the Maintenance Test Checklist.
