R Series Service Manual
1-28 9650-0903-01 Rev. L
15.0 Summary Report Test
Tools Needed: Impulse 4000.
Test Setup:
1. Connect the OneStep cable to the Impulse 4000
2. If you are using paddles, place the paddles on the analyzer’s discharge plates.
Do this... Observe this... Pass/Fail
15.1 Press the Report Data * softkey, press Erase,
then Erase All.
ERASING REPORT displays. Wait for the message to clear.
oo
15.2 Set selector switch to DEFIB (for AED units turn
to ON, and select MANAUL MODE.) Select
200J using the ENERGY SELECT button, and
press the CHARGE button. When charged,
press the SHOCK button to discharge into the
defibrillator analyzer.
The unit successfully discharges and if configured to do so, prints a strip chart.
oo
15.3 Wait 18 seconds, then press the Code Marker
softkey. Press the CPR softkey. Wait 20
seconds and turn unit off. (This will allow code
marker to be saved in the summary.)
The Code Markers display. (After CPR Code Marker is selected, the unit
automatically exits the Code Marker options menu.)
oo
15.4 Verify that the unit has been off for a minimum
of 10 seconds and then turn the unit on. Press
the Report Data * softkey, then press Print
Chart, then Print All.
Summary report prints. The report displays the correct date, time, the shock
delivered, and Code Marker event.
oo
* For software versions 3.0 or earlier, the unit displays Report instead of Report Data.
Record your results on the Maintenance Test Checklist.
