ZOLL R Series Service Manual

R Series Service Manual
9650-0903-01 Rev. L A-3
Delivered Energy at Every Defibrillator
Setting into a Range of Loads
* For all energy levels, accuracy is equal to either ±15% or 3 joules, whichever is greater.
Selected
Energy
Load
25 50 75 100 125 150 175 Accuracy*
1 J 1 J1 J1 J 1 J 1 J1 J1 J ±15%
2 J 1 J 2 J 2 J 2 J 2 J 2 J 2 J ±15%
3 J 2 J3 J3 J 3 J3 J3 J3 J ±15%
4 J 3J 4 J 4 J 5 J 5 J 5 J 4 J ±15%
5 J 3 J5 J6 J6 J6 J6 J6 J ±15%
6 J 4 J6 J 7 J7 J7 J7 J7 J ±15%
7 J 5 J7 J8 J8 J8 J8 J8 J ±15%
8 J 5 J 8 J 9 J 9 J 10 J 9 J 9 J ±15%
9 J 6 J 9 J 10 J 11 J 11 J 11 J 10 J ±15%
10 J 7 J 10 J 12 J 12 J 12 J 12 J 12 J ±15%
15 J 10 J 16 J 17 J 18 J 18 J 18 J 17 J ±15%
20 J 14 J 21 J 23 J 24 J 24 J 24 J 23 J ±15%
30 J 21 J 32 J 35 J 36 J 37 J 36 J 35 J ±15%
50 J 35 J 54 J 59 J 61 J 62 J 61 J 59 J ±15%
70 J 49 J 76 J 83 J 85 J 87 J 86 J 83 J ±15%
75 J 53 J 81 J 89 J 91 J 93 J 92 J 89 J ±15%
85 J 60 J 92 J 101 J 104 J 106 J 104 J 101 J ±15%
100 J 71 J 109 J 119 J 122 J 125 J 123 J 119 J ±15%
120 J 85 J 131 J 143 J 147 J 150 J 147 J 143 J ±15%
150 J 107 J 164 J 180 J 183 J 188 J 184 J 179 J ±15%
200 J 142 J 230 J 249 J 253 J 269 J 261 J 260 J ±15%

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
