ZOLL R Series Service Manual

R Series Service Manual
9650-0903-01 Rev. L 1-25
13.0 Synchronized Cardioversion for Remote ECG Monitoring Test (Optional)
If applicable, the R Series may be configured to receive defibrillation synchronization pulses from a remote ECG monitoring device (see the R Series
Configuration Manual). Remote Sync should be tested as a complete system that includes the remote monitor and R Series defibrillator. Be sure that the
remote device is connected to the Sync In/Marker Out connector on the R Series unit. The remote device must have a sync out connector and you must use
a cable to connect the two devices. Ensure the remote device conforms with the Sync In/Marker Out specifications described in Appendix A: Defibrillator
Specifications of the R Series Operator’s Guide.
Tools Needed: Fluke Biomedical 4000 or equivalent defibrillator analyzer.
Test Setup:
1. Connect the OneStep cable via the adapter (D.N.I #3010-0378) to the defibrillator analyzer.
2. Select cardioversion on analyzer. Input 1mV ECG signal at 60 -120 BPM.
Do this... Observe this... Pass/Fail
13.1 Connect the remote monitor’s ECG lead cable
to the defibrillator analyzer. Connect the
R Series OneStep cable via the adapter (D.N.I.
#3010-0378) to the defibrillator analyzer.
13.2 Select Defib Mode. Press the SYNC ON/OFF
softkey. Press the REMOTE SYNC softkey.
The words REMOTE SYNC are displayed in place of the ECG trace, and a
REMOTE SYNC XXXJ SEL. message appears on the display. The ECG
heartbeat indicator will flash with each synchronization pulse received from the
remote monitoring device. On the remote device’s display, verify that sync
markers coincide with each R-wave as described in the remote device’s user
manual.
oo
13.3 Select 200J on the R Series. Enter
synchronized cardioversion timing test mode on
the defibrillator analyzer.
oo
13.4 Press the CHARGE button. When the SHOCK
button lights, press and hold the SHOCK
button.
The defibrillator discharges. Observe that the R-wave to shock delay (sync
delay) is less than 60 milliseconds on the analyzer display.
oo
Record your results on the Maintenance Test Checklist.

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
