APPENDIX ASPECIFICATIONS
A–14 www.zoll.com 9650-0904-01 Rev. N
R Series Rectilinear Biphasic Waveform
Characteristics
Table A-1 shows the characteristics of the R Series Rectilinear Biphasic
®
waveform when
discharged into 25 ohm, 50 ohm, 100 ohm, 125 ohm, 150 ohm and 175 ohm loads at the
maximum energy setting of 200 joules.
Table A-1. R Series Rectilinear Biphasic Waveform Characteristics
200 J discharged into
25 50 100 125 150 175
First phase
Maximum initial current 31.4 A 30.4 A 19.7 A 19.4 A 16.7 A 15.6 A
Average current 27.1 A 24.9 A 17.5 A 16.2 A 14.4 A 13.2 A
Duration 6 ms 6 ms 6 ms 6 ms 6 ms 6 ms
Interphase duration
(between first and
second phases)
200 s 200 s 200 s 200 s 200 s200 s
Second phase
Initial current 29.2 A 18.8 A 15.1 A 13.2 A 12.1 A 11 A
Average current 14.7 A 13 A 12.5 A 11.3 A 10.7 A 9.9 A
Duration 4 ms 4 ms 4 ms 4 ms 4 ms 4 ms
Table A-2. Delivered Energy at Every Defibrillator Setting into a Range of Loads
Selected
Energy
Load
25 50 75 100 125 150 175 Accuracy
1 J 1 J1 J1 J 1 J 1 J1 J1 J ±3 J
2 J 1 J 2 J2 J2 J2 J2 J2 J ±3 J
3 J 2 J3 J3 J 3 J3 J3 J3 J ±3 J
4 J 3J 4 J 4 J 5 J 5 J 5 J 4 J ±3 J
5 J 3 J5 J6 J6 J6 J6 J6 J ±3 J
6 J 4 J6 J 7 J7 J7 J7 J7 J ±3 J
7 J 5 J7 J8 J8 J8 J8 J8 J ±3 J
8 J 5 J8 J9 J9 J10 J9 J9 J ±3 J
9 J 6 J 9 J 10 J 11 J 11 J 11 J 10 J ±3 J
10 J 7 J 10 J 12 J 12 J 12 J 12 J 12 J ±3 J
15 J 10 J 16 J 17 J 18 J 18 J 18 J 17 J ±3 J
20 J 14 J 21 J 23 J 24 J 24 J 24 J 23 J ±15%
30 J 21 J 32 J 35 J 36 J 37 J 36 J 35 J ±15%
50 J 35 J 54 J 59 J 61 J 62 J 61 J 59 J ±15%
70 J 49 J 76 J 83 J 85 J 87 J 86 J 83 J ±15%
75 J 53 J 81 J 89 J 91 J 93 J 92 J 89 J ±15%
85 J 60 J 92 J 101 J 104 J 106 J 104 J 101 J ±15%
100 J 71 J 109 J 119 J 122 J 125 J 123 J 119 J ±15%
120 J 85 J 131 J 143 J 147 J 150 J 147 J 143 J ±15%
