R Series Service Manual

9650-0903-01 Rev. L 4-41

Disassembling the System Brick Assembly

Refer to the diagrams beginning on page 4-43 for details.

System Brick Replacement Parts

Diagram number Part Number Description Torque

1 1009-0910-02 Assembly, Shielded Analog System Board, 3/5 Lead

2 9310-0883 Isolator, PD Engine to Analog PCB

3 9310-0796 Standoff, Male (single use only) 6 inch-lbs

4 9310-0797 Standoff, Female (single use only)

5 1009-0909-01 Assembly, PD Engine, Capacitor

6 9301-0509-01 Assembly, PCB, Digital Board

7 0163-0429 Scr. #5-20 X 0.250" 4 inch-lbs

8N/A N/A

9 9310-0798 Post, Corner

10 0163-1222 Scr. #5-20 X 3/8" 6 inch-lbs

11 9330-0768 Spacer

12 3005-0001 MS-11 Board

13 9330-0762 Adhesive, SpO

, PCB

14 9310-0889 Isolator, SpO

, PCB

15 9330-0763 Adhesive, SpO

, Isolator

16 9320-0744 Bracket, Heatsink (SpO

only)

17 9330-0737 Pad, 1.00 X .50, Rubber

18 9320-0765 Bracket, Heatsink and Parameter PCB Mounting
