R Series Service Manual

4-42 9650-0903-01 Rev. L

19 9301-0537-01 Assembly, PCB, Parameter PS (SpO

only)

20 0163-0151 Scr. #4-40 X 1/4" 6 inch-lbs

21 9310-0979 Isolator, IPS, EtCO

/NIBP

22 9330-0762 Adhesive, SpO

, PCB

23 9301-0510-01 Assembly, PCB, Parameter Power Supply

24 9310-0892 Isolator, IPS

25 0163-0151 Scr. #4-40 X 1/4" 6 inch-lbs

26 0550-0025 Tape, Kapton 0.001 THK .25" X 36 yards

27 9500-0771 Cable, Flex, MS-11 to ISO Power Supply

28 9500-0817 Assembly, Cable, 51 cond, ISO Power Supply

29 9301-0526-01 Assembly, PCB, ECG Interconnect, Flex Cable

30 0550-0001 Tape, Kapton, 3/4" wide 0.0025" THK 36 yards

31 0140-5237 Conn EMI Suppression Plate, 2x.2MM Pitch

32 0140-5236 Conn EMI Suppression Plate, 2X2MM Pitch

Diagram number Part Number Description Torque

Other manuals for ZOLL R Series
